Stock	20
ISO Size	20FT ISO - 6058mm x 2438mm x 2591mm
Material Tank Body	Stainless Steel 316L

Approvals by Lloyd's Register, the Netherlands

T11 ISO Tank Container

Download Technical Details
info@danteco.com
+31 10 351 00 22
Approved by international statutory authorities for the safe transportation of liquid hazardous, non-hazardous, and food cargoes and products

Danteco offers a full range of 20FT T11, 14 to 26,000-litre ISO Tank Containers. All tanks have the highest quality design and construction and conform strictly to the latest international approvals. Our tank container fleet is separated for four transportation purposes: tank containers for liquid chemical products, tank containers exclusively for liquid foodstuff, and tank containers for bitumen and fuel liquid products.

All tanks have the highest quality design and construction and conform strictly to the latest international approvals.

Customer-orientated, flexible service
Complete range of capacities and types
Top-quality design and construction
Tanks are available from central locations
Available for sale and lease

Why use ISO tanks?

ISO Tanks deliver real-time and labour savings while making door-to-door transport a smooth operation. Loaded and discharged using standard in-plant liquid transfer systems, tanks are lifted using standard ISO equipment. The switch between road, rail, and sea or storage at a destination is safe, straightforward, and economical. T11 tanks are approved to the highest standards by international statutory authorities for the safe transportation of a wide range of liquid products and, in particular, the following:

Liquids

with a flashpoint of less than 0° C
Certain high-hazard toxins or corrosives
Spontaneously combustible materials
Cargoes that are dangerous when exposed to moisture
Oxidizing substances

Please note that in certain exceptional cases, the containers operated by Danteco may have specifications that differ from the descriptions above.

Also, cargo in a container must conform to the dimensional regulations and laws stipulated by the host country; thus, payload capacity may be affected.

For more information or assistance, please get in touch with our customer service.

SPECIFICATION T11 ISO TANK CONTAINER 20FT

6058mm x 2438mm x 2591mm, General Purpose Tank Container, for hazardous and non-hazardous chemicals

6.0 bar test pressure, 4 bar working pressure, insulated, steam heated.

Year manufactured: Used Refurbished & New Build

Dimensions:
	Metric	Imperial
Capacity	25000 LTR	5500 US GALLONS
Maximum Gross Weight	34000 KG	74957LBS
Tare	3680KG	8113 LBS
Construction:
Working Pressure	4.0 bar	58 psi
Test Pressure	6.0 bar	87 psi
Steam Working Pressure	4.0 bar	58 psi
Steam Test Pressure	6.0 bar	87 psi
Relief Valve Set Pressure	4.4 bar	63 psi
Ambient Temp. Range	-40°C to +65°C	-40°F to +149°F
Maximum Cargo Temp	130°C	248°F
Shell Material	Stainless steel, ASTM A240 316 / 316L low carbon <0.03% DIN 17441 w1.4401. Cold rolled shell 2B finish. Thickness nominal 4.2mm shell +0.1 corrosion allowance, 4.65 ends, and equivalent 6mm mild steel per regulations.
Design Code / Approvals	ASME, Section VIII, Division 1 where applicable and IMDG T11, US Dot CFR 49 T11, ADR, RID, UIC, CTC, AAR, CSC, TIR. ISO.
Standard Fittings:
Manlid	500mm (20") diameter, 8 point fixing, 14mm x 12mm seal.
Calibration	Volumetric stainless steel chart.
Airline / Vapour	40mm (1½") ball valve Guard, outlet 1½ " BSP, stainless steel screw cap.
Relief Valve	80mm (3") DN65 flanged Guard high flow, operating pressure 4.4 bar, weld-in flange plugged provision for a second flanged valve.
Top Outlet	Blanked weld-in flange drilled 6 M12 holes @ 168 pcd, provision for optional fitting of 80mm (3") stainless steel butterfly valve. DN80, ASA 150 bolted blank flange outlet, 80mm (3") removable full-length syphon tube.
Bottom Discharge	80mm(3") Guard high lift foot valve and Guard clamped 80mm (3") butterfly valve. Outlet 3" BSP screw thread and cap.
Remote Closure	The bottom valve closure device is fitted together with the provision of a fusible link.
Gaskets & Seals	Parts in contact with cargo, PTFE/Teflon.
Steam Heating	7.5m² (80'²) effective surface area, eight external steam ducts, ¾" BSP screw inlet/outlet, and cap. Maximum pressure 4 bars. Tank max temperature 130°C.
Insulation	50mm (2") total comprising 50mm mineral wool 55 kg/m3 (CFC free) semi-rigid stiffened at top and covered by 0.8mm grade 5251 H44 aluminum pre-painted cladding, estimated thermal value 37 Kcal/hr at 30°C.
Compartment	Open stainless steel spill compartments with provision for optional lids.
Document Holder / Earth	Fitted at the rear end, suitable for shipping papers, MSDS, etc. The Earth is located at the rear.
Data Plate / Markings	Data Plate / Markings.
Walkway	Aluminium Q grating with access to top fittings, extending to the front end. Provision for an optional handrail. A ladder at rear RHS (rear hand side)
Temperature Gauge	80mm dia dual scale -20°C to 200°C / 0 to 400°F.

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
